HKS-1400-U2 Basic Parameters
| Model | HKS-1400-U2 |
|---|---|
| Max. loading jumbo roll width | 1400 mm |
| Max. loading jumbo roll diameter | Φ1400 mm |
| Max. loading jumbo roll weight | 1000 kg |
| Unwind paper tube inner core diameter | 3" (76mm) |
| Web guide sensor | Ultrasonic sensor |
| Cutting length | 20-1000 mm |
| Cutting precision | ±0.2 mm |
| Cutting speed | 30-150 cuts/min |
| Edge trimming system | Blowing fan |
| Cutting thickness | 80-500gsm |
| Total power | 16 kW |
| Power supply | 380V,3P,50HZ |
| Air supply | 0.6-0.8 Mpa, 0.8m3/Min |
| Weight | 6000 kg |
| Overall Dimension (L×W×H) | 9000×2400×2000 mm |
Basic Parameters
| Model | CQS-1100 | CQS-1400 | CQS-1600 |
|---|---|---|---|
| Max. Material Width | 1100 mm | 1400 mm | 1600 mm |
| Max.Unwinder Roll Diameter | Φ1400 mm | Φ1400 mm | Φ1400 mm |
| Cutting Length | 100-500 mm | 100-500 mm | 100-500 mm |
| Cross Cutting Speed | 30-200 times/min | 30-200 times/min | 30-200 times/min |
| Precision of Cross Cutting | ±0.2 mm | ±0.2 mm | ±0.2 mm |
| Cutting Thickness | 30-500 g/m² | 30-500 g/m² | 30-500 g/m² |
| Max. Pile Stack Height | Max.50 mm | Max.50 mm | Max.50 mm |
| Total Power | 12 kw | 14 kw | 18 kw |
| Machine Weight | 4000 kg | 4500 kg | 5300 kg |
| Overall Dimension (L×W×H) | 7500×2300×1800 mm | 7500×2600×1800 mm | 7500×2900×1800 mm |
