Basic Parameters
| Model | HKA-1600 |
|---|---|
|
Max. Diameter of Unwinding |
Φ1500 mm |
|
Max. Cutting Width |
1400 mm |
|
Cutting Length |
20-1200 mm |
|
Machine Speed |
20-180 times/min |
|
Put (slitting) speed |
20-140 times/min |
|
Paper GSM |
20-500 g |
|
Cutting Precision |
±0.2 mm |
|
Ream Height (mm) |
500 pcs |
|
Total Power |
About 12 kW |
|
Machine Weight |
4500 kg |
|
Compressed air(Mpa) |
0.6-0.8 Mpa(Customer's own responsibility) |
|
One machine need 3KW air compressed; if the factory has one big compressed air, it will be better. |
|
|
Main power source |
380V/50HZ, 3phase 4 wires |
|
Machine Size (L×W×H) |
4500×3200×1800 mm |
