Air-Cooled Pelletizing Machine
SJ-B90/100/110/120 Series

Air-Cooled Pelletizing Machine

Air-Cooled Pelletizing Machine is an efficient and environmentally friendly plastic recycling pelletizing equipment, adopting air-cooling technology, suitable for recycling and pelletizing various plastic scraps and waste plastics. The machine automatically completes the whole process of melting, extrusion, pelletizing, air cooling, and material collecting, with precise temperature control, uniform pelletizing, and regular particle forming. It does not require water resources for cooling, saving energy and water, easy to operate and stable in operation, widely used in the plastic recycling and processing industry to help resource recycling.
  • Diameter of screw:
    Φ 90
  • Output capacity:
    68 kg/hr
  • Rotational speed of screw:
    10-110 r/min
GET IN TOUCH
    Product Specifications

    Basic Parameters

    Model SJ-B90 SJ-B100 SJ-B110 SJ-B120
    Diameter of screw Φ90 Φ100 Φ110 Φ120
    Ld of screw 20:1 - 22:1 20:1 - 22:1 20:1 - 22:1 20:1 - 22:1
    Rotational speed of screw 10-110 r/min 10-110 r/min 10-110 r/min 10-110 r/min
    Main motor power 22kw 30 kw 37 kw 45 kw
    Output 68 kg/hr 95 kg/hr 120 kg/hr 135 kg/hr
    Weight 2600 kg 2800 kg 3000 kg 3200 kg
    Outline dimension (L×W×H) 4000×1500×1800 mm 4200×1500×1800 mm 4400×1500×1800 mm 4600×1500×1800 mm
    Optional Upgrades
    Crusher
    Crusher
    REQUEST A QUOTE FOR YOUR MACHINES
    You receive a quote this machine according to standard configuration.
    REQUEST NOW
