VESTP-430*2 Series

Bag Making Machine Vest Bag Making Machine

Name: Bag Making Machine Vest Bag Making Machine
Brand: CHENQI
SKU: 00070
Rating: 4.9 (85 reviews)

Chenqi Full Automatic High-Speed Plastic Vest Bag Making Machine, Two Lanes Automatic Bag Sorting. Custom fully automatic bag sorting and bag packaging.

Max sealing & cutting width:
430 mm
Sealing & cutting length:
320~700 mm
Sealing & cutting thickness:
0.005～0.05 mm

GET IN TOUCH

Product Overview

VESTP-430*2 Full Automatic Vest Bag Making Machine is here to solve your plastic bag production headaches! Full Servo Diven, Fully automatic bag sorting and portioning.

Product Specifications

Basic Parameters

Model	VESTP-430*2
Maximum Sealing and Cutting Width	430 mm
Sealing and Cutting Length	320~700 min
Sealing and Cutting Thickness	0.005~0.05 mm
Error in Length	±1 mm
Bag-making Speed	40~350 pcs/min×2
Power of Main Motor	2.4×22 kw
Heating Power	2 kw
Total Power	10 kw
Weight of Machine	2500 kg
Overall Dimensions (L×W×H)	7500×1950×1800 mm

Optional Upgrades

Punching Machine

Conveying Table

EPC

Product Details

REQUEST A QUOTE FOR YOUR MACHINES

You receive a quote this machine according to standard configuration.

REQUEST NOW
