ABA CO-EX AUTO Series

ABA Film Blowing Machine

Name: ABA Film Blowing Machine
Brand: CHENQI
SKU: 00024
Rating: 4.9 (62 reviews)

ABA film blowing machine is an advanced piece of equipment widely used in the field of plastic film manufacturing.

Film width:
400-1200 mm
Film thickness:
0.02-0.10 mm
Max. extrusion output:
HDPE: 120-130 kg/hr
LDPE: 150-200 kg/hr

GET IN TOUCH

Product Overview

This equipment is mainly used for producing high-quality plastic films, with significant characteristics such as high plasticity, high strength, and uniform thickness. The products produced by ABA film blowing machines are widely used in many fields. For example, T-shirt shopping bags, biodegradable plastic films, and fruit packaging.

Product Specifications

Basic Parameters

Model	ABA-900	ABA-1100	ABA-1300
Suitable material	HDPE LDPE LLDPE	HDPE LDPE LLDPE	HDPE LDPE LLDPE
Film width	400-800 mm	500-1000 mm	600-1200 mm
Flim thickness	0.02-0.10 mm	0.02-0.10 mm	0.02-0.10 mm
Max. extrusion output	HDPE: 120kg/hr LDPE:150kg/hr	HDPE: 123kg/hr LDPE:180kg/hr	HDPE:130kg/hr LDPE:200kg/hr
Screw diameter	Φ50×2	Φ55×2	Φ55×1 Φ65×1
Screw I/d length	32:1	32:1	32:1
Die size	LDPE: 180 HDPE: 80	LDPE:220 HDPE: 100	LDPE:250 HDPE:120
Air blower	5.5kw×1	5.5kw×1	7.5kw×1
Roller width	900 mm	1100 mm	1300 mm
Take-up motor	1.5 kw	1.5 kw	2.2 kw
Winding motor	16 N.m	16 N.m	16 N.m
Outline dimension (L×W×H)	4.8×3.2×5.5 m	5×3.5×6 m	5×3.7×7.5 m

Optional Upgrades

Auto Loader

Corona Treater

High-Speed Screen Changer

Air Shaft

Metric Weight Control Device

Air Compressor

Dryer

Mixer

Product Details

REQUEST A QUOTE FOR YOUR MACHINES

You receive a quote this machine according to standard configuration.

REQUEST NOW
